skychopper

– Octocopter Compozite Airframe
– Diameter: 1030mm
– Vehicle Mass: 8Kg
– Payload: 2Kg
– Endurance: 50min
– Cruissing Speed: 10m/s
– Wind Tolerance: 10m/s

Triple redundant vibration damped IMU with support for up to 3 GPS modules

– Wireless Visible Distance (with 2.1db antenna): 15-22km
– Sending Power Output: 1mW-1W(0-30db)
– Serial Transmitting Speed: 10-230bps/400bps
– Transmitting Speed: 9600bps/115kbps/200kbps
– Wireless RF Transmission speed: 125kbps
– Working Temperature: -40~85 C
– Working Frequency: ISM 902-928MHz
– Spread Spectrum: FHSS
– Networking Topology: Peer to Peer, Peer to Point,
Point to MultiPoint
– Channel: 10 hop sequences share 50 frequencies
– Encryption: 256bit/128bit AES
– Certificates: FCC, IC, C-TICK
